| Technical data and specifications |
| Reference standards |
IEC 60252-1 |
| Safety class according IEC 60252-1 |
P0 |
| Life expectancy to IEC 60252-1 |
3,000 h( C)~10,000 h(B) |
| Rated capacitance CR |
1 µF~120 µF |
| Tolerance |
±5% |
| Rated voltage VR |
110VAC~630VAC |
| Rated frequency FR |
50/60Hz |
| Maximum ratings |
| Maximum permissible votage Vmax |
1.1*VR (VR=Rated voltage) |
| Maximum permissible current Imax |
1.3*IR (IR=Rated current) |
| Test data |
| AC test voltage terminal to terminal VTT |
2*VR, 2s (routine test) |
| 2*VR, 60s (type test) |
| Dissipation factor tan δ |
≤0.002 (50Hz) |
| Climatic data |
| Climatic category |
25/085/21 to IEC 60068-1 |
| Lower category Tmin |
-25ºC |
| Upper category Tmax |
+85ºC |
| Damp heat test Ttest |
21 days |
